AT-112 active loudspeakers

SKU: AT-112
0.0 (0)
0 Sold
$280.00 $300.00

Key Features

  • Professional build: Crafted from high-quality plywood for durability and superior acoustic performance

  • Design: Innovative, compact, and versatile, suited for both portable and fixed installations

  • Sound quality: Produces clear, powerful, and precise audio across all frequency ranges

  • Applications: Ideal for houses of worship, DJ setups, bars, stage monitoring, touring, museums, and other sound reinforcement uses

  • Performance: Engineered for consistent clarity, reliability, and high output in demanding environments

Received successfully
Coupon Code
CONTINUE SHOPPING
Quantity:
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
1/1
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Soni-112A active loudspeakers
  • Description

Type

Active DSP-controlled full range loudspeaker

Frequency Response(-10dB)

42Hz-20kHz

Horizontal Coverage

90°/60°

Vertical Coverage

60°/90°

Maximum Calculated SPL/1M (Continuous/Peak)

128dB/134dB

HF Driver

Customized driver, 1.75” voice coil and 1.0”exit

LF Driver

Customized 12” driver, 3.0” voice coil

DSP

Processor

48kHz signal sampling frequency,FIR filtering

Presets

MAIN,LF BOOST,W/SUB

AMPLIFIER

Amplifier Circuitry

Class D

Power (RMS standards)

1100W

Peak Power

2200W

Frequency Response(1W 8Ω 2ch)

20Hz-20kHz(±0.5dB)

Intermodulation Distortion

<0.05%

Total Harmonic Distortion

<0.05%

Cooling System

Cooling with fans, air convection

Protection

DC protection, short circuit protection, overheat protection, input overload protection, output overload protection, soft startup protection, overvoltage protection, undervoltage protection

Signal Input

Female XLR(Mono jack 6.35)

Signal Output

Male XLR

Power Input

IEC power connector

Working Voltage

100-130V~ or 220-240V~ (±10%,50/60Hz)

Power consumption (1/8 output power)

95W

CABINET



Cabinet Material

CNC machined plywood

Coating

Durable Polyurea Coating

Cabinet Color

Black is the default color. Contact design for customization

Grille

Iron mesh

Handles

2 side

Monitor Angle

Symmetrical 45° monitoring Angle

Hanging Hardwares

M8 screw

Pole Mount

Base hole Φ35mm,0° or 10° options

Speaker Dimension (W×H×D)

355x599x349mm

Carton Dimension (W×H×D)

446×688×446mm

Net Weight

21.0kg

Shipping Weight

24.0kg
