AUDIOPEAK Amplifier – Key Features

• Global Adaptive Wide Voltage: Operates from 90V to 264V, ensuring reliable performance under variable power conditions.

• Class D Amplifier with PFC: High-efficiency amplification with Power Factor Correction for energy-optimized operation.

• Digital Gain Control: Precise digital gain reduction for accurate sound management.

• Advanced Cooling System: Temperature-controlled, continuous variable-speed fan with front-to-back airflow.

• Temperature Monitoring: Forecast and historical temperature display via LCD for proactive thermal management.

• Comprehensive Protection: Safeguards against overheating, AC/DC faults, short circuits, overload, clipping, and long-term amplifier stress.

• LCD Matrix Interactive Display: Clear, intuitive interface for real-time monitoring.

• User-Friendly Front Panel Menu: Easy access to settings and system control.

• Security: Optional password protection to lock settings and prevent unauthorized changes.

Channel-Specific Features:

• Built-in, disableable clipping limiter per channel

• Gate functionality that can be disabled

• User-selectable gain/sensitivity

• Adjustable maximum output power per channel

• Selectable maximum power supply current consumption

Specifications:

• Maximum Output Power (EIAJ Test Standard):

  • Stereo: 2×2700W/8Ω, 2×5200W/4Ω, 2×9000W/2Ω

  • Bridge: 10000W/8Ω, 18000W/4Ω

• Working Voltage: 90V–264V

• Gain Options: 26dB / 29dB / 32dB / 35dB

• Input Sensitivity: 7.37V / 5.22V / 3.68V / 2.62V

• Frequency Response: 20Hz–20kHz (±0.5dB) @1W, 8Ω

• S/N Ratio: >110dBA (20Hz–20kHz, A-weighted)

• Crosstalk Isolation: >66dB @1kHz

• THD＋N: <0.3% (1W to full power)

• DIM100: <0.3% (1W to full power)

• Input Impedance: 10kΩ balanced

• Conversion Rate: 50V/μs @8Ω, input filter bypassed

• Damping Factor: >5000 @20–200Hz

• Dimensions (L×H×W): 483mm × 44.5mm × 475mm

• Weight: 13.5kg
